tungsten boat

tungsten boat

Tungsten boat is widely used in gold plated control, evaporator, imaging lens, the heating

container, spray paint of electron beam, household appliances (shell), mobile phones, toys, and various accessories such as vacuum coating industry and sintering furnace for sintering

or vacuum annealing in ship industry.

Ideal  (vacuum, dry), at the two ends of the tungsten boat connecting  electricity  wires , and put

the low melting point metal placed in the middle of the sunken place under the temperature to

2000 degrees, the metal will evaporate into gas, plating on the workpiece surface.

        Name

Symbol of products

Size(mm)

Trough Length  (mm)

Trough Depth  (mm)

W1

99.95%pure tungsten

boats

FM210

0.2*10*100

50

2

FM215

0.2*15*100

50

7

FM216

0.2*25*118

80

10

FM308

0.3*8*100

50

2

FM310

0.3*10*100

50

2

FM310

0.3*10*70

40

1.8

FM312

0.3*12*100

50

2

FM313

0.3*13*49

33

3.3

FM315

0.3*15*100

50

7

FM316

0.3*16*100

50

4

FM318

0.3*18*100

40

3.5

FM514

0.5*14*100

50

2.6

FM515

0.5*15*100

50

2.6



   Also we can delivery the tailor-made Tungsten boats according to your drawings or individual demands
