Polished Gr5 Ti6al4v Straight Titanium Wire



Product Features

    Titanium Wire is slivery metal with excellent properties. Density is 4.54g/cm³ lighter than Steel. But mechanical strength is higher than Steel, 2 times stronger than Aluminium, 5 times stronger than Magnesium. Pure Titanium Wire is high temperature resistance and melting point is 1942K.

    High Qualiy Titanium Wire has low density, light weight, high strength, also has the good corrosion resistance, high temperature resistant, low temperature resistance, acid resistance, alkali resistance and so on.

    Titanium wire can be applyed in different walks of life. Such as military industry, medical, sporting goods industry, glasses, earring, headwear, plating hangers, welding wire etc.







GRADE

SPECIFICATIONS

AWS A5.16

ASTM B863

AMS

Commercial Pure Titanium

ERTi-1,2,3,4

ASTM B863 Gr1,2,3,4
ASTM F67 Gr1,2,3,4

AMS 4951
AMS 4921

Ti 6Al-4V

ERTi-5

ASTM B863 Gr5

AMS 4954

Ti 6Al-4V Eli

ERTi-5 Eli

ASTM B863 Gr23
ASTM F136 Eli

AMS 4956

Ti (0.12~0.25)Pd

ERTi-7

ASTM B863 Gr7

----

Ti 3Al-2.5V

ERTi-9

ASTM B863 Gr9

----

Ti 0.3Mo-0.8Ni

ERTi-12

ASTM B863 Gr12

----



DIAMETER & TYPES

DIAMETER RANGE

TYPES
mm inch Coil Spool Straight
0.05 to 0.78 0.002 to 0.031 Yes Yes No
>0.78 to 3.25 >0.031 to 0.128 Yes Yes Yes
> 3.25 to 6.00 > 0.128 to 0.236 Yes No Yes

* Diameter Tolerance: +/-0.05mm (+/-0.002”) or finer
* Spools: 100mm – 300mm (3.9” – 12”)
* Straight Length: 300mm - 3000mm (12” – 118”)
