Medical titanium wire

Material

Pure Titanium and Alloy Titanium

Grade

TC4,GR5,TI-6AL-4V.TI-6AL-4V ELI,TC20,

Standard

GB/T13810-2007,ASTM F136,ISO 5832-3,ISO5832-11,ASTM F1295.

Specification

Diameter 0.05 - 6 mm, Length - Spools: 100mm - 300mm - Straight: 300mm - 3000mm

Surface Treatment

Polishing

Black, Pickling, Sand-blasting



Features

light weight, acid and alkali resistance, anti-corrosion, excellent mechanical strength etc.

Applications

Equipment accessories: airplane, ship, bicycle, motorcycle, automobile, medical, chemical, wheel, sports, anchor, weapon, etc.



 Titanium Wire Specifications

Grade Specifications
AWS A5.16 ASTM B863 AMS
Commercial Pure Titanium ERTi-1,2,3,4 ASTM B863 Gr1,2,3,4 AMS 4951
ASTM F67 Gr1,2,3,4 AMS 4921
Ti 6Al-4V ERTi-5 ASTM B863 Gr5 AMS 4954
Ti 6Al-4V Eli ERTi-5 Eli ASTM B863 Gr23 AMS 4956
ASTM F136 Eli
Ti 0.2 Pd ERTi-7 ASTM B863 Gr7 -
Ti 3Al-2.5V ERTi-9 ASTM B863 Gr9 -
Ti 0.3Mo-0.8Ni ERTi-12 ASTM B863 Gr12 -

DIAMETER & TYPES

Titanium Wire Diameters and Types

DIAMETER & TYPES
DIAMETER RANGE TYPES
mm inch Coil Spool Straight
0.05 to 0.78 0.002 to 0.031 Y Y N
>0.78 to 3.25 >0.031 to 0.128 Y Y Y
> 3.25 to 6.00 > 0.128 to 0.236 Y N Y

Diameter Tolerance: +/-0.05mm (+/-0.002”) or finer Spools: 100mm – 300mm (3.9” – 12”) Straight Length: 300mm - 3000mm (12” – 118”)



HOT SALE BAOJI FUTURETI-  titanium fishing wire smallest diameter

Chemical Requirements

Element

(max)

Grade

Gr1

Gr2

Gr5

Gr7

Gr12

N

0.03

0.03

0.05

0.03

0.03

C

0.08

0.08

0.08

0.08

0.08

H

0.015

0.015

0.015

0.015

0.015

Fe

0.20

0.30

0.40

0.30

0.30

O

0.18

0.25

0.20

0.25

0.25

Al



5.5-6.75



V



3.5-4.5



Pa



0.12-0.25




0.2-0.4



0.6-0.9

Ti

balance

balance

balance

balance

balance



Tensile Requirements

Grade

Tensile Strength (min)

Yield strength 0.2%Offset

Elongation in 2in. or 50mm % (min)

Min

Ksi

Mpa

Ksi

Mpa

Gr1

35

240

20

138

20

Gr2

50

345

40

275

18

Gr3

65

450

55

380

18

Gr5

130

895

120

828

10

Gr7

50

345

40

275

18

Gr12

70

483

50

345

18
