Zirconium elbow Zr702, Zr705

Type

30 Degree:  1.5 Radius ,3radius, 5radius

30°:  1.5D,3D,5D

45 Degree:  1.5 Radius ,3radius, 5radius

45°: 1.5D ,3D,5D

60 Degree :1.5 Radius ,3radius, 5radius

60°:  1.5D,3D,5D

90 Degree, 1.0Radius, 1.5 Radius ,3Radius, 5Radius

90°:  1.0D,1.5D,3D,5D

180Degree,1.0Radius ,1.5 Radius ,3Radius, 5Radius

180°:  1.0D,1.5D,3D,5D

Grade

Pure Zirconium and Alloy Zirconium R60702,R60704,R60705

Specification

Outer Diameter   DN15-1200  NPS 1/2"-48"

Wall Thickness  2MM-30MM    SCH5S-SCH160

Standard

ASME B16.9-2007    ,    MSS SP 43-1991 , MSS SP 75-2008

Technique

Butt welding    Seamless

Surface Finished

Sand Blasting     Polishing

Quality Control

100% X-RAY or Dye Penetrate Test

Application

petroleum, chemical industry, electric power, metallurgy, pharmacy, shipyard and other similar yield.
