TB8 GR21(Ti-15Mo-3Al- 2.7Nb-0.25Si) titanium bar
TB8 GR21(Ti-15Mo-3Al- 2.7Nb-0.25Si) titanium bar
|
Product name |
TB8 gr21 Titanium bar |
|
Standard |
ASTM B348 |
|
Material |
Ti-15Mo-3Al- 2.7Nb-0.25Si |
|
Certificate |
ISO 9001-2008 |
|
Density |
0.168 lb/inch³ |
|
Dimensions |
round:dia.:3~350mm,length:<15000mm,square: can be produced according to your requirement |
|
Section shape |
Round, square and hexagonal |
|
Material characteristics |
High strength and hardness, Lighter than Ti-6Al-4V,superior resistance to stress corrosion cracking |
|
Applications |
1.hand-made forging and die forging;2.Aircraft landing gear;3.golf clubs control handle;4. Make knives tools |
Chemical compositions of Ti-15Mo-3Al- 2.7Nb-0.25Si
|
Grade |
ELEMENT COMPOSITION.% |
|||||||||||
|
|
Ti |
Al |
Mo |
Nb |
Si |
Fe |
C |
N |
H |
O |
Other |
|
|
Gr21 |
Min |
Bal |
2.5 |
14.0 |
2.2 |
0.15 |
0.4 |
0.05 |
0.03 |
0.015 |
0.17 |
0.3 |
|
Max |
Bal |
3.5 |
16.0 |
3.2 |
0.25 |
- |
- |
- |
- |
- |
- |
|
Mechanical Properties of Gr21 titanium bar
|
Grade |
Tensile Strength(min) |
Yield Strength(min) |
Elongation(%) |
Reduction(%) |
|
Mpa |
Mpa |
|||
|
Gr21 |
1526 |
1414 |
15.5 |
|
The main production process of titanium bar
Smelting —> Forging —> Rotary Forging —> Annealing Straightening —> Peeling —> Centerless
grinding —> Detecting —> Packing as following
